Bateson 40LT Double Axle Livestock Trailer| Fieldfare Trailer Centre

Availability: Call Fieldfare Trailers for Information 01980 611853

Model 40LT is rated at 2 tons gross with a 2.7m long body allowing an increased carrying capacity but also still able to be towed by a standard car or similar light vehicle.

All Livestock models have a hot dipped galvanised chassis. Furthermore the panels are made from panelled with 2mm toughened alloy and a plastic coated galvanised steel roof. The floor is made from 18mm Phenol coated panels covered with aluminium tread-plate and a folded tread-plate ramp door. As a result, making the Bateson range of Livestock Trailers ideal for a wide range of users due to the diverse model options

The 40LT is fitted with full width independent suspension axles and auto-reversing brakes. A side door, ramp side gates, front jockey wheel, locking hitch and spare wheel are all standard

In addition a cross division gate is also available as an option. Maximum permitted pen lengths are 3.6m for cattle, 3m for sheep and pigs and 2.4m for calves. The 40LT is available with simple lift out decks with a rear ramp section


Model 40LT Trailer Specifications

Gross Weight KG 2000 Unladen Weight KG 650 Capacity 1350

Internal Dimensions in millimetres Length 2700 x Width 1500 x Height 1800

Tyre Size 165 x 13 Tow Ball Height 400mm

Trailer PDF
